AKY0638 Li-Po batteries with protection are an advanced power source with a wide range of applications. They have a capacity of 1200 mAh and a nominal voltage of 3.7V. The technology used allows for a small battery size, without limiting the freedom to choose the capacity. That is why lithium-polymer batteries from Akyga are ideally suited to power all kinds of portable devices of various sizes and shapes. In addition, the PCM protection used protects the batteries against overcharging, excessive discharge and short circuit, and the 150 mm long cables attached to it, terminated with a 2.54 JST 2 pin connector, facilitate installation.
The battery is compliant with the following certificates: CE, RoHS, MSDS.
Before installation, familiarize yourself with the rules of using lithium polymer batteries. Incorrect use may lead to their damage.
- Product code AKY0638
- Part number LP603450
- Responsible Entity Ropla Elektronik HP Sp. z o.o., 52-200 Suchy Dwór, Wrocławska 1c, Polska/Poland, [email protected]
- Product type Polymer Li-Ion Battery
- Rated voltage 3.7 V
- Battery capacity 1200 mAh
- Protection PCM
- Leads wires, connector+socket
- Thickness 6 mm
- Width 34 mm
- Height 50 mm
- Connector type 2,54 JST, 2 pins
- Connector part number JST SYP-02T-1
- Cable length 100 mm
- Package UniBag
- Product size (L x W x H) 50 x 34 x 6 mm
- Net weight 22 g
- CE compatibility Yes
- RoHS compatibility Yes
- MSDS compatibility Yes
- EAN code 5906574243520
- Warranty 24 months
