The Akyga® AK-C2-800 ATX power supply from the Classic series is an excellent choice for those seeking stable and reliable power for their PC systems. This semi-modular ATX power supply delivers 800 W, making it ideal for both office PCs and home workstations. Thanks to its compliance with the 80 PLUS certification, it operates efficiently, reducing power losses and supporting eco-friendly use. Additionally, the active PFC optimises the power factor, reducing energy consumption.
Rich set of connectors
The Akyga® AK-C2-800 ATX power supply is equipped with a variety of connectors that allow flexible connection of multiple components. Modular connectors include:
- One 8-pin (4+4-pin) connector
- Four PCI-E 6+2-pin connectors
- Three Molex plugs
- Six SATA plugs
A fixed 20+4-pin connector guarantees a stable connection to the motherboard. The modular cables, ranging from 50 to 80 cm in length, are flat, facilitating cable management inside the case, improving airflow, and simplifying the installation process.
High-Quality Components
One of the key strengths of the AK-C2-800 power supply is the use of cutting-edge electronic components that meet current technological standards. Carefully selected components ensure the durability and stability, guaranteeing reliability during intensive use.
Elegant Design and Efficient Cooling
The semi-modular power supply comes in a sleek black casing that complements most computer cases, providing a modern and professional look. Inside, a quiet 120mm fan ensures effective airflow, maintaining optimal operating temperatures without increasing noise levels.
Reliable Power Source
The Akyga® AK-C2-800 ATX power supply is a reliable and efficient solution for demanding users looking for a stable power source for their advanced computer systems. Choose this semi-modular power supply to ensure your computer receives the highest quality and reliability.
- Product code AK-C2-800
- Product type Computer power supply
- Format ATX 2.31
- Series Pro Modular
- Responsible Entity Akyga Europe Sp. z o.o., 52-200 Suchy Dwór, Wrocławska 1c, Polska/Poland, [email protected]
- Supply voltage 230 V
- Power consumption < 5 A
- Efficiency > 70 %
- 80 PLUS compatibility Yes
- Current on the +3.3V rail 13 A
- Current on the +5V rail 13 A
- Maximum load on +3.3V and +5V line 105 W
- Current on the +12V rail 57 A
- Maximum load on 12V line 800 W
- Maximum power 800 W
- Mainboard Power Connector 20+4-pin
- Power connector ATX12V P4 None
- Power connector EPS12V 8 pin 1 pc ( 4 + 4-pin )
- Power connector PCI-E 6 pin None
- Power connector PCI-E 6+2 pin 4 pcs
- Power connector PCI-E 8 pin None
- Molex connector 3 pcs
- SATA connector 6 pcs
- Modular power supply Semi-modular
- PFC filter Active
- Mechanical switch Yes
- Ground wire Yes
- OVP Yes
- OCP Yes
- OPP Yes
- OTP Yes
- SCP Yes
- UVP None
- Power supply connector IEC C14
- Fan size 120 mm
- Fan adjustments Automatic
- Cable length 50 - 80 cm
- The cable plug #1 Hybrid standard C/E/F ( CEE 7/7 )
- The cable plug #2 IEC C13
- Power cable included Yes
- Material Galvanized steel
- Product color Black
- MTBF 100000 h
- Temperature 5 - 50 °C
- Package EcoBox
- Product size (L x W x H) 150 x 145 x 85 mm
- Package size (L x W x H) 235 x 180 x 100 mm
- Net weight 1.7 kg
- Gross weight 1.82 kg
- CE compatibility Yes
- FCC compatibility No
- RoHS compatibility Yes
- REACH compatibility Yes
- Included accessories Power cable
- EAN code 5901720139573
- Warranty 24 months
